Шаблон

Модель

Размер решетки
（Дл.X Шир.）

Размер подложки

(Дл.X Шир）

Ползучесть

мм

мм

BF(BA)200-4AA(**)

4.0X2.2

8.0X3.6

BF(BA)200-6AA(**)

6.0X2.3

10.7X4.8

ZF(BA)300-1AA(**)

1.1X1.3

3.6X2.2

BF(BA)300-3AA(**)

2.9X1.8

5.5X2.5

BF(BA)350-1AA(**)N*

1.5X2.5

4.5X3.5

N3,N0,N8,N6,N4,N2,T0,
T2,T4,T6,T8

BF(BA)350-2AA-A(**)

2.4X3.0

4.9X4.0

BF(BA)350-2AA-P(**)N*

2.0X2.4

5.0X3.5

N0,N2,T0,T2,T4,T6,T8

BF(BA)350-2AA(**)N*
ZF1000-2AA(**)N*

2.5X3.3

6.5X4.5

N9,N7,N5,N3,N1,N0,N8,N6,N4
N2,T0,T2,T4,T6,T8,T1

BF350-3AA-A(**)N*

3.2X1.57

6.9X3.1

N8,N6

BF(BA)350-3AA(**)N*

3.2X3.1

7.4X4.4

N9,N7,N5,N3,N1,N0,N8,N6,N4,
N2,T0,T2,T4,T6,T8,T1,T3,T5

ZF1000-3AA(**)N*

3.2X3.2

7.4X4.5

N0,N8,N6,N4,N2

BF(BA)350-4AA(**)N*
ZF1000-4AA(**)N*

3.8X2.7

8.2X4.2

BF(BA)350-5AA(**)N*
ZF1000-5AA(**)N*

5.0X2.9

9.3X4.5

BF(BA)350-6AA(**)

6.1X3.1

10.4X5.4

BF(BA)500-4AA(**)

4.0X3.3

7.9X4.6

BF(BA)600-4AA(**)

4.2X4.0

8.6X5.8

BF(BA)650-4AA(**)

4.0X4.4

8.6X6.0

BF(BA)650-5AA(**)

5.0X3.9

9.0X5.6

BF(BA)650-6AA(**)

5.8X4.4

10.4X6.4

ZF1000-1.5AA(**)T*

1.5X4.0

4.9X5.2

T8

ZF1000-1.5AA-A(**)N*

1.5X2.5

4.5X3.1

T8,T3

BF1000-2AA(**)N*

2.2X4.6

5.8X5.8

N0,N8,T6,T8

ZF1000-2AA-A(**)T*

2.1X3.3

5.8X4.5

T8

BF(BA)1000-3AA(**)T*

3.0X5.3

6.7X6.5

N3,N1,N8,N6,N4,T0,T2,T6

BF(BA)1000-4AA(**)N*

4.0X4.3

7.7X5.5

BF(BA)1000-6AA(**)

6.0X4.0

9.9X5.4

ZF2000-2AA(**)N*

2.0X3.0

5.6X4.5

T6

ZF2000-2AA-A(**)T*

2.1X4.2

5.4X5.2

T6

ZF2000-3AA(**)T*

3.2X4.0

7.4X5.3

T4

ZF2500-3AA(**)N*

3.2X3.2

7.4X4.5

N0,N8,N6,N4,N2,T0,T2,T4,
T6,T8

ZF3000-6AA(**)T*

6.1X3.9

9.8X5.2

T4
